Product Overview
The GCS low voltage withdrawable switchgear is a high-density, operation-friendly drawout power distribution solution optimized for large-scale industrial production, commercial power distribution and municipal engineering projects. Tailored for global 400V/50Hz low-voltage power systems, this drawout type low voltage switchgear adopts a professional rotary propulsion drawer mechanism and 20mm modular installation standard, supporting multi-layer dense layout. Different from conventional switchgear, it features labor-saving operation, high circuit integration and strong unit interchangeability, making it the ideal choice for scenarios requiring intensive power distribution and frequent equipment maintenance. As a high-performance industrial power distribution device, it stably supports continuous power supply for manufacturing workshops, industrial parks and municipal utility systems.
Core Product Features
High-Density Modular Layout:
Adopting 20mm precise modular design, the cabinet supports up to 11 layers of standard drawer units, realizing more circuit configurations within the same floor area compared with ordinary switchgear. It greatly improves power distribution density, saves substation room space and effectively reduces infrastructure construction costs for industrial and commercial projects.
Labor-Saving Rotary Drawer Mechanism:
Equipped with exclusive CJG series rotary propulsion structure, the drawer pushing and pulling process is smoother and more labor-saving. The optimized mechanical structure avoids jamming and misoperation during unit insertion and withdrawal, significantly improving daily operation efficiency and on-site maintenance convenience for engineering personnel.
Multi-Level Mechanical Interlock Protection:
Built-in reliable mechanical interlock device strictly complies with international safety operation specifications. It realizes safe locking in isolation, test and working positions, effectively preventing live-line drawing, wrong switching and other dangerous operations. The independent compartment isolation design isolates busbars, circuits and control units to eliminate arc flash safety hazards.
Stable and Durable Structure:
The whole cabinet is made of high-strength assembled steel frame with electrostatic anti-corrosion spraying treatment, featuring strong structural rigidity and excellent impact resistance. The internal busbar is equipped with flame-retardant isolation protection plates, which inhibits arc spread and ensures long-term stable operation in complex indoor power distribution environments.
Strong Compatibility and Expandability:
Standardized drawer units achieve high universal interchangeability, supporting free combination of incoming, outgoing, motor control and reactive power compensation loops. The flexible structural design allows later circuit expansion and function upgrade without overall cabinet modification, adapting to iterative upgrade requirements of modern industrial power systems.
Technical Specifications
|
Parameter |
Technical Value |
|
Product Model |
GCS Low Voltage Withdrawable Switchgear |
|
Rated Working Voltage |
AC 400V, 50Hz |
|
Rated Insulation Voltage |
660V |
|
Main Busbar Rated Current |
630A – 4000A |
|
Rated Short-Time Withstand Current |
Up to 50kA (1s) |
|
Protection Grade |
IP30/IP40 (IP54 Optional) |
|
Modular Standard |
20mm high-density modular layout |
|
Executive Standard |
IEC 61439-1/-2, GB/T 7251.1 |
|
Application Scenarios |
Industrial manufacturing, municipal engineering, industrial parks, commercial complexes |
Application Scenarios
This high-performance LV withdrawable switchgear cabinet is widely applicable to medium and large-scale power distribution scenarios with high density and frequent maintenance demands. It is perfectly suitable for automated manufacturing workshops, chemical and metallurgical industrial plants, urban municipal power distribution stations, large commercial buildings and logistics industrial parks. Relying on its dense wiring and flexible maintenance advantages, the withdrawable power distribution switchgear effectively solves the problems of insufficient space and difficult maintenance in traditional power distribution rooms, becoming the preferred power distribution equipment for new and renovated industrial projects.
Why Choose Our GCS Switchgear (Google EEAT Standard)
We strictly abide by Google EEAT optimization principles of professionalism, experience, authority and trustworthiness, focusing on the R&D and customized production of high-density drawout type low voltage switchgear. With professional technical accumulation, rich overseas project experience, authoritative qualification certification and reliable full-cycle service, we provide stable and cost-effective power distribution solutions for global engineering contractors and end-users.
Professional Expertise (E):
Our technical team focuses on high-density drawout low-voltage power distribution system design, proficient in GCS exclusive rotary propulsion mechanism and modular layout logic. We can scientifically optimize drawer layer distribution and loop configuration according to customer site space and load parameters, avoiding space waste and matching the high-efficiency power supply demands of modern industrial projects.
Practical Industry Experience (E):
We have undertaken a large number of overseas industrial supporting and municipal power distribution projects, accumulating mature experience in adapting to different regional power grid standards and site construction conditions. We are familiar with the acceptance specifications of Southeast Asia, Middle East, Africa and other markets, and can provide targeted design and delivery schemes to ensure smooth project commissioning and acceptance.
Authoritative Qualification Support (A):
All products are manufactured in strict accordance with IEC international standards, with complete CE certification, ISO 9001 quality system certification and factory type test reports. All technical indicators are authentic and compliant, supporting third-party independent inspection and project filing, with high industry authority and recognition.
Trustworthy Quality & Service (T):
Realize full in-house processing from sheet metal fabrication, busbar processing to assembly and testing, with strict multi-process quality inspection to ensure stable product performance. We provide 12-24 months official warranty, complete English technical documents and drawings, as well as 24-hour online remote technical support, solving customers' on-site operation and maintenance problems efficiently.
Get Custom Quote
If you are looking for high-density, labor-saving and safe LV withdrawable switchgear cabinet for industrial or municipal power distribution projects, please provide your electrical single-line diagram, load parameters and site requirements. Our professional engineering team will provide you with personalized configuration scheme, detailed technical drawings and competitive quotation within 24-48 hours.
Stable performance and flexible configuration make our withdrawable power distribution switchgear a cost-effective upgrade solution for modern low-voltage power distribution systems.
