Product Overview
The Low Voltage Withdrawable MCC Motor Control Center Draw-out Cabinet is a professional centralized motor control and low-voltage power distribution solution developed for large and medium-sized industrial production systems. Different from fixed conventional distribution cabinets, this integrated Industrial motor control center integrates motor start-up, operation control, circuit protection, signal monitoring and power distribution management in one modular cabinet. Adopting advanced draw-out structural design, this high-reliability Draw‑out MCC switchgear supports quick plugging, withdrawing and replacement of functional units, greatly reducing equipment maintenance downtime and improving industrial production continuity. As a standardized and intelligent Factory motor‑control cabinet, it is widely used in automated production lines, chemical plants, metallurgy, mining and other heavy industrial scenarios, providing stable and centralized operational control for large-scale industrial motor groups.
Core Product Features
Modular Draw-out Structure & Fast Maintenance:
This professional Draw‑out MCC switchgear adopts an independent drawer-type functional unit design, with complete mechanical interlock protection. Each motor control unit can be freely withdrawn, inspected and replaced without powering off the entire cabinet. The universal interchangeability of drawer units effectively solves the problem of difficult maintenance and long fault recovery time of traditional fixed switchgear, significantly improving industrial operation and maintenance efficiency.
Centralized Motor Group Intelligent Control:
As a high-efficiency Industrial motor control center, the equipment supports centralized management of multiple motor loops, covering full functions such as motor direct start, soft start, frequency conversion operation and overload short-circuit protection. It realizes unified monitoring and precise control of factory motor equipment, avoiding scattered and difficult-to-manage decentralized motor control modes, and optimizing the overall industrial power control system architecture.
Industrial-Grade Safety & Arc Resistance Performance:
This heavy-duty Factory motor‑control cabinet adopts multi-compartment isolated structural design, which physically separates busbar room, cable room and functional unit room. Equipped with arc-proof and explosion-proof devices and multi-level electrical interlock mechanisms, it effectively prevents arc flash faults and mis-operation risks. The whole cabinet meets industrial high-standard safety specifications, adapting to long-term continuous operation in harsh industrial environments.
Stable Power Supply & Strong Load Adaptability:
The built-in high-capacity insulated busbar system has excellent current-carrying capacity and short-circuit resistance, which can stably bear the impact of frequent start and stop of industrial high-power motors. It supports 50/60Hz dual-frequency operation, compatible with global industrial low-voltage power standards, ensuring stable and reliable power output and motor operation status in complex industrial working conditions.
High Integration & Space Saving Layout:
Highly integrated modular configuration realizes intensive arrangement of multiple control loops in a single cabinet. Compared with scattered single-motor control cabinets, it saves on-site installation space, simplifies on-site wiring and construction procedures, and reduces overall industrial electrical engineering investment and later operation costs.
Technical Specifications
|
Parameter |
Technical Standard |
|
Product Name |
Low Voltage Withdrawable MCC Motor Control Center Cabinet |
|
Rated Working Voltage |
AC 380V/400V/660V, 50/60Hz |
|
Rated Insulation Voltage |
Up to 1000V |
|
Rated Current |
Horizontal Bus ≤4000A, Vertical Bus ≤1600A |
|
Short-Time Withstand Current |
Up to 85kA (1s) |
|
Protection Grade |
IP40~IP43 (Indoor Industrial Standard) |
|
Structure Type |
Withdrawable / Draw-out Modular Structure |
|
Executive Standard |
IEC 61439, IEC 60439 |
|
Applicable Load |
Industrial motor groups, pumps, fans, compressors |
Application Scenarios
This high-performance Draw‑out MCC switchgear is specially designed for industrial centralized motor control scenarios, widely applied in chemical industry, metallurgy, mining, water treatment, building materials manufacturing and large factory automated production lines. As a core industrial electrical device, the professional Industrial motor control center provides unified and efficient control solutions for large-scale factory motor equipment. The durable Factory motor‑control cabinet is suitable for both new industrial electrical supporting projects and old factory electrical system upgrading and renovation, helping enterprises realize standardized and intelligent management of motor equipment.
Product Strengths & Factory Professionalism
Our factory is a professional manufacturer of industrial-grade low-voltage withdrawable MCC control centers, with years of R&D and manufacturing experience in heavy industrial motor control and power distribution equipment. We focus on solving industrial equipment maintenance difficulties, low control efficiency and poor system stability, providing high-standard electrical solutions for global heavy industrial projects.
Professional Industrial Electrical R&D Strength:
The technical team deeply masters the operation characteristics of industrial motor groups and harsh working condition requirements, optimizing the drawer interlock structure, arc-proof protection system and anti-vibration design. The product effectively adapts to frequent motor start-stop and long-term high-load operation, solving the stability pain points of traditional MCC cabinets.
Rich Overseas Heavy Industry Project Experience:
We have supplied bulk MCC draw-out switchgear for overseas chemical, metallurgical, mining and factory power distribution projects. Familiar with international industrial electrical standards and project acceptance specifications, we can provide targeted customized configuration according to different regional industrial working conditions.
Full Qualification Compliance & Authoritative Certification:
All products are manufactured in strict accordance with IEC international industrial standards, with complete ISO9001 quality system certification, CE certification and third-party industrial electrical test reports. Complete English technical documents and qualification files are provided to support overseas project bidding, filing and third-party acceptance.
Strict Industrial-Grade Quality Control:
All products pass full-load operation test, short-circuit resistance test and mechanical interlock reliability test before delivery. We provide 18-24 months long-term factory warranty and 24-hour online professional technical support, ensuring stable operation of customer industrial production systems.
Get Custom Quotation
Please inform us of your required voltage level, motor loop quantity, rated current and special protection requirements. Our professional technical team will provide you with customized industrial-grade configuration scheme and competitive quotation within 24-48 hours.
